Transition Networks 10/100 Bridging Converter, RJ-45 to 100Base-FX MM SC, Box
- Item #:
- Category:
- Availability:
- Packaging:
- Platform:
- Condition:
- Brand:
- B-76830
- Media Converters
- Item is in stock
- Retail Packaging
- Windows
- New
- Transition Networks
Click to enlarge
Product Rating
(0 Ratings)
General Information
Stand-alone Fast Ethernet Media and Rate Converter 10/100Base-TX to 100Base-FX The SBFTF Series is a that provides an interface between 10/100Base-TX ports and 100Base-FX ports, allowing users to integrate fiber optic cabling into 10/100 copper environments. Operating at Layer 2, the data link layer, this converter not only converts copper to fiber, it also provides rate conversion allowing legacy 10Base-T copper devices to connect to 100Base-FX fiber. |
Interfaces/Ports
| Total Number of Ports: | 2 |
| Network (RJ-45): | Yes |
| Number of Network (RJ-45) Ports: | 1 |
| Number of SC Ports: | 1 |
Media & Performance
| Media Type Supported: | Optical Fiber |
| Media Type Supported: | Twisted Pair |
| Fiber Mode Supported: | Multi-mode |
| Fiber Optic Cable Wavelength: | 1300 nm |
| Maximum Data Transfer Rate: | 100 Mbit/s |
| Maximum Distance Supported: | 2 km |
Network & Communication
| Ethernet Technology: | Fast Ethernet |
| Network Technology: | 100Base-FX |
| Network Technology: | 10/100Base-TX |
Power Description
| Power Source: | AC/DC |
| Input Voltage: | 12 V DC |
Physical Characteristics
| Form Factor: | Wall Mountable |
| Form Factor: | DIN Rail Mountable |
| Form Factor: | Rack-mountable |
| Form Factor: | Standalone |
| Form Factor: | Shelf Mount |
| Height: | 1" |
| Width: | 3.3" |
| Depth: | 4.8" |
| Weight (Approximate): | 2 lb |
Miscellaneous
| Package Contents: | |
| Application/Usage: | Data |
| Application/Usage: | Network |
| Additional Information: | 10/100Base-TX (RJ-45) [100 m/328 ft.] to 100Base-FX 1300nm multimode (SC) [2 km/1.2 mi.] Link Budget: 11.0 dB |
| Certifications & Standards: | Safety: Wall Mount Power Supply: UL Listed; FCC Class A, VCCI Class 1, CISPR22/EN55022 Class A, EN55024, EN61000, CE Mark |
| Environmentally Friendly: | Yes |
| Environmental Compliance: | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Environmental Compliance: | Restriction of Hazardous Substances (RoHS) |
| Environmental Compliance: | Waste Electrical and Electronic Equipment Directive (WEEE) |
| TAA Compliant: | Yes |
| NDAA Compliant: | Yes |
Warranty
| Limited Warranty: | Lifetime |
Be the first to review this product. Write a Review
Shipping Restrictions
- This item cannot be shipped to PO Boxes.
- This item can be shipped only within the U.S.
- UPC: 648177025480
- Mfr's Part #: SBFTF1013-105-NA
